Hunter Heavy Duty Equipment
Row# | Part# | Description | Manufacturer's List Price Dated | Contract Delivered Price Dated |
|---|---|---|---|---|
|
row# |
DSP740T |
4 Cordless HD Sensor set w/ Self-Centering Wheel Adaptors. (Req. WinAlign HD 14.2 or ProAlign HD 2.0) Rolling Comp requires WinAlign plus key. (standard w/WT400 models) 20-2916-1 extenders included. |
$13,300.00
|
$13,300.00
|
|
row# |
DSP760T |
6 Cordless HD truck/bus Sensor set with Self-Centering Wheel Adaptors. (Requires WinAlign HD 14.2 or newer software & Plus Key) 20-2916-1 extenders included. |
$19,000.00
|
$19,000.00
|
|
row# |
20-2974-1 |
DSP700T Upgrade Kit- Upgrades DSP740T sensors to DSP760T sensors. Includes two sensors, two wheel clamps, hangars, and all items included normally with DSP760T. (Req. WinAlign HD 14.2 or newer & Plus key (Plus key is standard w/ WT400 models) |
$6,100.00
|
$6,100.00
|
|
row# |
WT623 |
HD Aligner with column/wall mount cabinet and 24″ Widescreen LCD Display. Includes truck pusher and plus key. |
$19,418.00
|
$19,418.00
|
|
row# |
WT522 |
HD Aligner with column/wall mount cabinet and 24″ Widescreen LCD Display. Note: There is no provision for storage or charging of cordless conventional sensors when using this configuration. |
$13,930.00
|
$13,930.00
|
|
row# |
PT262 |
HD Aligner with mobile cabinet, 24″ LCD Flat Panel Display, and color printer. DSP740T sensors only. |
$7,200.00
|
$7,200.00
|
|
row# |
WT572 |
HD Aligner with New compact cabinet and 24″ Wide Screen LCD Display. |
$14,490.00
|
$14,490.00
|
|
row# |
WT673 |
HD Aligner with New premium compact cabinet and 24″ Wide Screen LCD Display. Includes Truck Pusher and Plus Key. |
$20,520.00
|
$20,520.00
|
|
row# |
WT674 |
HD Aligner with New premium compact cabinet and 27″ Wide Screen LCD Display. Includes Truck Pusher and Plus Key. |
$20,890.00
|
$20,890.00
|
|
row# |
WT674BLK |
HD Aligner with New premium compact cabinet and 27″ Wide Screen LCD Display. Includes Truck Pusher and Plus Key. Black. |
$20,890.00
|
$20,890.00
|
|
row# |
WT683 |
HD Aligner with New premium large cabinet and 24″ Wide Screen LCD Display. Designed for use with HE421 passenger car sensors for Combo LD/HD users. Cabinet does not support HD sensor storage. Includes Truck Pusher and Plus Key. |
$21,490.00
|
$21,490.00
|
|
row# |
WT684 |
HD Aligner with New premium large cabinet and 27″ Wide Screen LCD Display. Designed for use with HE421 passenger car sensors for Combo LD/HD users. Cabinet does not support HD sensor storage. Includes Truck Pusher and Plus Key. |
$22,010.00
|
$22,010.00
|
|
row# |
WT684BLK |
HD Aligner with New premium large cabinet and 27″ Wide Screen LCD Display. Designed for use with HE421 passenger car sensors for Combo LD/HD users. Cabinet does not support HD sensor storage. Includes Truck Pusher and Plus Key. Black. |
$22,010.00
|
$22,010.00
|
|
row# |
WT685 |
HD Aligner with New premium large cabinet and 32″ Wide Screen LCD Display. Designed for use with HE421 passenger car sensors for Combo LD/HD users. Cabinet does not support HD sensor storage. Includes Truck Pusher and Plus Key. |
$22,310.00
|
$22,310.00
|
|
row# |
WT685BLK |
HD Aligner with New premium large cabinet and 32″ Wide Screen LCD Display. Designed for use with HE421 passenger car sensors for Combo LD/HD users. Cabinet does not support HD sensor storage. Includes Truck Pusher and Plus Key. Black |
$22,310.00
|
$22,310.00
|
|
row# |
WT552 |
WT500 Standard WinAlign HD Embedded Console Option with 24″ Monitor, printer, and other required components. Mounting cabinet sold separately. |
$13,930.00
|
$13,930.00
|
|
row# |
WT653 |
WT600 Premium WinAlign HD Embedded Console Option with 24″ Monitor, printer, Plus Key, Truck Pusher, and other required components. Mounting cabinet sold separately. |
$19,418.00
|
$19,418.00
|
Row# | Part# | Description | Manufacturer's List Price Dated | Contract Delivered Price Dated |
|---|---|---|---|---|
|
row# |
38-512-1 |
10 Ft. Extension Cable – To extend sensor or remote indicator cable. |
$174.00
|
$174.00
|
|
row# |
20-1832-1 |
5 Position Battery Charger – Provides a charging station for up to 5 DSP500 Sensors batteries. The charger can be mounted in S or R cabinets built after September 2003 or as a free standing charger using AC Conversion Kit, 20-1864-1. |
$675.00
|
$675.00
|
|
row# |
20-1864-1 |
AC Conversion Kit – Allows the 5 Position Battery Charger, 20-1832-1, to be used as a free standing charger without using the aligner power supply. |
$180.00
|
$180.00
|
|
row# |
20-561-1 |
Adapter – Stud and Sleeve Kit (trucks) Includes 8 each of the following: Truck Adaptor Stud (134-51-1) Sleeve Stud (106-57-2) Storage Plug Assy (43-94-1) |
$105.00
|
$105.00
|
|
row# |
20-823-1 |
Adaptor – Rim Stud Extension Kit – (for 2 self-centering adaptors) Includes 8 Rim Stud Extensions (134-81-1) |
$100.00
|
$100.00
|
|
row# |
175-321-1 |
Adaptor – Self-Centering Wheel Adaptor – For DSP500 Sensors. Adaptor is not compatible with horseshoe style storage brackets. Clamping range – 10″- 24.5″ (4 required) |
$298.00
|
$298.00
|
|
row# |
20-1522-1 |
Adaptor – Spade Sleeve Kit – (for 2 self-centering adaptors) for rim guard tires. Includes 8 Rim Guard Tire Sleeves (106-118-2) |
$44.00
|
$44.00
|
|
row# |
20-1792-1 |
Adaptor – Wheel Adaptor Extension – (set of sixteen, covers 4 wheel adaptors) Increases maximum wheel diameter on self-centering adaptors by 3 1/2 inches. Compatible only with self-centering adaptors, 175-377-1, 175-321-1 and 175-325-1. |
$466.00
|
$466.00
|
|
row# |
20-1978-1 |
Adaptor – Wheel Off Adaptor – (set of two) Allows faster and accurate alignment adjustments by removing the wheel and attaching the sensor directly to the lugs. Includes 2 Wheel Off Adaptors 175-376-1. (Requires WinAlign 9.0) |
$224.00
|
$224.00
|
|
row# |
20-1979-1 |
Adaptor – Wheel Off Adaptor Magnet Assembly – (set of two) Attaches to Wheel Off Adaptors allowing connection directly to the rotor. Includes 2 Wheel Off Adaptor Magnet Assemblies 60-31-1. (Requires Wheel Off Adaptor Kit 20-1978-1 and WinAlign 9.0) |
$250.00
|
$250.00
|
|
row# |
20-1355-1 |
ALCOA Spade Adaptors Includes 8 Truck Rim Guard Tire Sleeves (106-103-2) |
$115.00
|
$115.00
|
|
row# |
20-1473-1 |
Alignment Trailer Dolly Kit – Allows rear DSP306T Series Sensors to be mounted to dolly eye of trailer. (Requires Trailer Gage Tool, 221-660-1) |
$351.00
|
$351.00
|
|
row# |
20-1488-1 |
Auxiliary DSP Sensor Charging Station – Provides a second charging station where cordless sensors and DSP400, DSP600, HS401 or HS400 Sensors are being used with the same console. |
$300.00
|
$300.00
|
|
row# |
20-3246-1 |
Bus body reference stands. |
$975.00
|
$975.00
|
|
row# |
20-2785-1 |
CodeLink 2 with Wireless Pod and expansion cable. Requires WinAlign version 11.0 or greater software and 2013 final release specs or newer (version 11.0-14.0 SAS reset functionality only). If ordering QC7X, WA67X-68X series consoles, order kit 20-2813-1. |
$1,415.00
|
$1,415.00
|
|
row# |
20-2813-1 |
CodeLink-CodeLink 2 and expansion cable without Wireless Pod. Requires WinAlign version 11.0 or greater software and 2013 final release specs or newer. Suitable for QC7X, WA/WT67X, and WA/WT68X consoles. |
$1,100.00
|
$1,100.00
|
|
row# |
20-2890-1 |
Conversion Kit- Converts DSP300T and DSP500T trailer gauge to work with DSP700T sensors. |
$150.00
|
$150.00
|
|
row# |
213-47-2 |
Convex Mirror 20″ x 30″. |
$160.00
|
$160.00
|
|
row# |
20-2882-1 |
Cordless Remote Indicator Kit – Includes Cordless Remote Indicator and recharging bracketry for 6,7, & 8 Series Cabinets |
$1,550.00
|
$1,550.00
|
|
row# |
194-23-2 |
Cordless Sensor Battery – For 500 Series Sensors and Plus Cordless Remote Indicator, 30-418-1 and Icon Cordless Remote Indicator, 30-421-1 (each) |
$30.90
|
$30.90
|
|
row# |
20-2760-1 |
DSP700 Battery charger- Provides a charging station for up to 6 DSP700 sensors batteries. |
$895.00
|
$895.00
|
|
row# |
232-283-1 |
DSP700T Remote Recharge- Charges up to six DSP700T sensors. Works with DSP700T cart, 20-2850-1. |
$652.00
|
$652.00
|
|
row# |
20-2901-1 |
DSP700T Sensor Recharge Kit- Adds charging outlets for up to six DSP700T sensors on WT600 and WT500 series modular cabinets. |
$228.00
|
$228.00
|
|
row# |
20-2928-1 |
DSP700T Sensor Storage Post Kit- Sensor storage NO charging capability. Each floor mounted post stores two sensors. Includes two posts, does not include mounting brackets. |
$650.00
|
$650.00
|
|
row# |
20-2886-1 |
DSP700T Sensor Storage Post Kit- Sensor storage with charging capability. Includes two posts, charger, and wiring. Each floor mounted post stores two sensors. Sensor brackets not included. |
$1,150.00
|
$1,150.00
|
|
row# |
20-3651-1 |
DSP740T Quick Grip storage. |
$1,115.00
|
$1,115.00
|
|
row# |
20-2927-1 |
DSP760T Battery Charger Kit- Includes battery charger for charging up to six DSP700 batteries, 120-240 volt power supply, and six DSP700 sensor batteries. |
$1,388.75
|
$1,388.75
|
|
row# |
69-1187-2 |
Equipment Cover for WA37x, WA47X, and R811/S811 M mobile cabinets without hangers and sensor or targets. |
$209.55
|
$209.55
|
|
row# |
69-1025-2 |
Equipment Cover for WA58x/68x cabinets with conventional passenger-car sensors/targets or HD truck cabinets. This cover will also fit S811s with DSP306T/506T and DSP400/600 sensors. |
$273.00
|
$273.00
|
|
row# |
194-27-1 |
Extra Battery for DSP700 sensor |
$95.00
|
$95.00
|
|
row# |
20-3294-1 |
Flush mount pocket with PowerSlide turnplates. |
$9,225.00
|
$9,225.00
|
|
row# |
20-3294-1BLK |
Flush mount pocket with PowerSlide turnplates. Black. |
$9,225.00
|
$9,225.00
|
|
row# |
20-3105-1 |
Frame Reference Gauges. For use during frame reference alignment. Contains two frame adaptors and four frame hook assemblies. Long hook assemblies available as kit 20-3104-1. |
$5,400.00
|
$5,400.00
|
|
row# |
20-3284-1 |
Gen II HD Truck Pusher- Battery operated truck rolling aid to move large vehicles for rolling compensation. Can be used as a wheel chock, rear axle adjustment aid, or for moving vehicles across shop. Battery charger included. |
$2,300.00
|
$2,300.00
|
|
row# |
20-3284-1BLK |
Gen II HD Truck Pusher- Battery operated truck rolling aid to move large vehicles for rolling compensation. Can be used as a wheel chock, rear axle adjustment aid, or for moving vehicles across shop. Battery charger included. Black. |
$2,300.00
|
$2,300.00
|
|
row# |
221-646-1 |
HD – Frame Offset Tool – Used to measure axle offset with reference to frame. For use with inspection and frame offset measurements in WinAlign HD. |
$232.00
|
$232.00
|
|
row# |
25-71-1 |
HD – Turnplate – 18″ Truck Audit (Two Required) Lower friction than standard turnplates. Intended for high through-put facilities and manufacturing plants. |
$1,040.00
|
$1,040.00
|
|
row# |
20-2710-1 |
HD – Turnplates ~ Two 18″ Truck Audit Turnplates. Torlon bearing equipped for lower friction and longer life. Intended for high through-put facilities and manufacturing plants. |
$2,080.00
|
$2,080.00
|
|
row# |
20-3512-1 |
HD MD Quick Grip adaptor spacers. Steps the 22.5″ adaptor bolt pattern down to 19.5″. Includes two spacers per kit. |
$85.00
|
$85.00
|
|
row# |
20-3507-1 |
HD Quick Grip adaptors. 2 axle application. |
$2,650.00
|
$2,650.00
|
|
row# |
20-3506-1 |
HD Quick Grip adaptors. 3 axle application. |
$4,010.00
|
$4,010.00
|
|
row# |
20-3508-1 |
HD Quick Grip adaptors. Front axle only. |
$1,290.00
|
$1,290.00
|
|
row# |
20-3509-1 |
HD Quick Grip adaptors. Middle axle only. |
$1,360.00
|
$1,360.00
|
|
row# |
20-3510-1 |
HD Quick Grip adaptors. Rear axle only. |
$1,360.00
|
$1,360.00
|
|
row# |
20-3520-1 |
HD Quick Grip front adaptor supports. |
$135.00
|
$135.00
|
|
row# |
20-3521-1 |
HD Quick Grip rear adaptor supports. |
$135.00
|
$135.00
|
|
row# |
175-377-1 |
HD Self-Centering Wheel Adaptor – For DSP500 Truck Sensors. Adj. center casting for clearance issues. Adaptor is not compatible with horse-shoe style storage brackets. Does not include Sleeve Rim Guard Kit 20-1643-1. Clamping range – 15″-28″ -4 required |
$325.00
|
$325.00
|
|
row# |
20-3525-1 |
HD sensor storage cart for HD Quick Grip or SC adaptors. |
$1,700.00
|
$1,700.00
|
|
row# |
20-2009-1 |
Heavy Duty Alignment Kit – Radar aiming fixture for heavy duty alignment. Can be used with kit 20-2770-1 Radar Aiming Attachment (Sold Separately). |
$4,310.00
|
$4,310.00
|
|
row# |
20-3104-1 |
Kit contains 4 long hooks for use with frame adaptors (20-3105-1) during frame reference alignment. |
$225.00
|
$225.00
|
|
row# |
221-652-1-T |
Long calibration bar includes 20-1596-1 truck base (required for the calibration of DSP306T HD alignment systems.) |
$880.00
|
$880.00
|
|
row# |
221-717-1 |
Long Calibration Bar Kit with Tall Stands. |
$725.00
|
$725.00
|
|
row# |
20-2902-1 |
Mini Wheel Adaptor Kit – Contains two mini wheel adaptor clamps 175-284-1. Mounts sensor to hub center of front rims. Clamping range – 8.75″ – 12″ |
$686.00
|
$686.00
|
|
row# |
20-3271-1 |
Mobile HD turnplate kit. Suitable for rolling or jacking compensation. |
$2,750.00
|
$2,750.00
|
|
row# |
20-3271-1BLK |
Mobile HD turnplate kit. Suitable for rolling or jacking compensation. Black. |
$2,750.00
|
$2,750.00
|
|
row# |
20-3431-1 |
Mobile HD turnplate storage trays. Storage trays mount to 20-2850-1 carts and may be retrofitted. Holds 2 sets of 20-3271-1 mobile turnplates. |
$247.50
|
$247.50
|
|
row# |
20-3431-1BLK |
Mobile HD turnplate storage trays. Storage trays mount to 20-2850-1 carts and may be retrofitted. Holds 2 sets of 20-3271-1 mobile turnplates. Black. |
$247.50
|
$247.50
|
|
row# |
20-2979-1 |
Passenger Car Accessory Kit- Includes CodeLink 2 (20-2813-1) Bar Code Reader (20-2900-1) and Ride Height Targets (20-2050-1) for use with WT400/600 Aligners. |
$2,290.00
|
$2,290.00
|
|
row# |
20-2880-1 |
Plus Remote Indicator Kit – Includes Plus Remote Indicator and recharging bracketry for 6,7, & 8 Series Cabinets |
$1,850.00
|
$1,850.00
|
|
row# |
136-95-2 |
Power Line Filter – Line conditioner used to suppress high frequency noise in the AC line (Standard with WA200, WA300, WA400 Series Aligners). |
$105.00
|
$105.00
|
|
row# |
20-3334-1 |
Rack mount sled with PowerSlide turnplates. |
$8,475.00
|
$8,475.00
|
|
row# |
20-2056-1 |
Remote Hanger Recharge Kit – Allows mounting and recharging of the Plus and Icon Cordless Remote Indicator Wireless in different locations. Ships standard with Plus Cordless Remote Indicator, 30-418-1 and Icon Cordless Remote Indicator, 30-421-1. |
$265.00
|
$265.00
|
|
row# |
175-288-1 |
Self Centering Mini Wheel Adaptor – Mounts sensor to hub center of front rims. Same as 175-284-1 but uses the standard rim stud on the end castings. Clamping range – 8.75″ – 12″ (Two Required) |
$343.00
|
$343.00
|
|
row# |
175-284-1 |
Self Centering Mini Wheel Adaptor – Mounts sensor to hub center of front rims. Adaptor has double ended rim studs that grip the inside of the center of the wheel. Clamping range – 8.75″ – 12″ (Two Required) |
$343.00
|
$343.00
|
|
row# |
20-2916-1 |
Sensor Shaft Extension Kit- Contains two adaptors for extending sensors out from wheel adaptors to account for differences in offsets or body overhangs. |
$225.00
|
$225.00
|
|
row# |
20-1643-1 |
Sleeve Rim Guard Kit Includes 8 DSP Truck Rim Guard Tire Sleeves (106-129-2) (Standard with DSP306T Sensors) |
$105.00
|
$105.00
|
|
row# |
20-3291-1 |
Surface mount Sled with PowerSlide turnplates for rolling compensation. Permanent installation easily supports a wide variety of track widths. |
$9,500.00
|
$9,500.00
|
|
row# |
20-3291-1BLK |
Surface mount Sled with PowerSlide turnplates for rolling compensation. Permanent installation easily supports a wide variety of track widths. Black. |
$9,500.00
|
$9,500.00
|
|
row# |
221-527-1 |
Tire Measuring Tool (Standard with DSP306T and DSP306T-HFSS sensors) |
$294.00
|
$294.00
|
|
row# |
221-738-1 |
Trailer Gauge Tool (new style) – Allows rear DSP truck series sensors to be mounted to trailer. Will work with all DSP series truck sensors. |
$915.00
|
$915.00
|
|
row# |
20-1592-1 |
Turnplate ramps for on floor alignment |
$220.00
|
$220.00
|
|
row# |
20-2538-1 |
VIN Bar Code Reader Kit – Includes Bar Code Reader and shelf. |
$840.00
|
$840.00
|
|
row# |
20-2820-1 |
WA300/WA400 to WinAlign HD Software upgrade kit. Upgrades Standard WinAlign machines to WinAlign HD machines running WA version 14.x. Requires HW1 or HW1B PC be present for the upgrade. |
$4,470.00
|
$4,470.00
|
|
row# |
20-2770-1 |
WABCO Radar Tool – Radar aiming attachment for WABCO OnGaurd Collision Mitigation systems. Can be used with 20-2009-1 Radar Aiming Fixture for HD trucks. |
$275.00
|
$275.00
|
|
row# |
11-1589-1 |
Wheel clamp support bracket for 700 series sensors. Includes hardware to install one rubber bumper. Bracket mounting hardware NOT included. |
$90.00
|
$90.00
|
|
row# |
20-3397-1 |
WinAlign HD HW2 Upgd Kit – Upgrade to the latest WinAlign HD PC hardware. No exch/del. Note this upgd kit requires a Gen II USB box, Windows 10 compatible printer, min 17″ UVGA monitor and HD software be present. |
$3,740.00
|
$3,740.00
|
|
row# |
20-3399-PSR-1 |
WinAlign HD HW2 with Gen III USB box upgd Kit – Upgds any HD console config to the latest WinAlign HD hdw. Required for 211T/411T/611T. No exch/deletions. Requires Windows 10 compatible USB color printer, min 17″ UVGA monitor and HD software be present. |
$5,240.00
|
$5,240.00
|
|
row# |
20-2005-1 |
WinAlign Plus Electronic Key Kit ~ Kit includes WinAlign Plus Software Required for Hawkeye Elite Sensors. |
$4,740.00
|
$4,740.00
|
|
row# |
20-3323-1 |
WinAlign~ HD 15 software upgrade. Includes keys, the latest spec database and Installation/Training by Hunter Service Rep. Requires HW1B PC. A standard HD WinAlign Aligner key must be present for the upgrade. |
$880.00
|
$880.00
|
|
row# |
20-3337-1 |
WinAlign~ HD 15 software upgrade. Requires HW1B PC. Adds Heavy Duty functionality to a light vehicle aligner. |
$4,470.00
|
$4,470.00
|
|
row# |
20-3621-1 |
WinAlign~ HD 16 software upgrade. Includes keys, the latest spec database and Installation/Training by Hunter Service Rep. Requires HW2 PC. A standard HD WinAlign Aligner key must be present for the upgrade. |
$880.00
|
$880.00
|
|
row# |
20-3622-1 |
WinAlign~ HD 16 software upgrade. Requires HW2 PC. Adds Heavy Duty functionality to a light vehicle aligner. |
$4,470.00
|
$4,470.00
|
|
row# |
20-2656-1 |
WinHD Software Upgrade kit – Adds HD software & specifications to an existing WinAlign WA Series console. Software upgraded to version WA12.x for pre HW1/HW1B PC systems. Not compatible with 811 & older consoles. Does NOT include HD Sensors, turnplates. |
$4,470.00
|
$4,470.00
|
|
row# |
20-2881-1 |
Wired Remote Indicator Kit – Includes cabled Remote Indicator and storage bracketry for 6,7, & 8 Series Cabinets |
$975.00
|
$975.00
|
|
row# |
20-3197-1 |
Wireless Network Kit – connects a WinAlign WA Aligner to a shop’s existing 802.11 ac/a/b/g/n wireless network. NOT included with console upgrades. |
$180.00
|
$180.00
|
|
row# |
2030-T |
Wood Truck model-For demonstrating the principles of heavy duty wheel alignment. Aluminum wheels and rubber tires with independent adjustment. Walnut wood body. |
$35.00
|
$35.00
|
|
row# |
20-2072-1 |
XF2 Pod Kit – XF pod for Plus Cordless Remote Indicator, 30-418-1-1 and Icon Cordless Remote Indicator, 30-421-1. XF2 Pod shipped standard with DSP500 Cordless Sensors after 6-27-06 and is not compatible with DSP500 Cordless Sensors built before 6-27-06. |
$315.00
|
$315.00
|
Row# | Part# | Description | Manufacturer's List Price Dated | Contract Delivered Price Dated |
|---|---|---|---|---|
|
row# |
FM02 |
ForceMatch HD Balancer-Includes SmartWeight, TPMS Specs (passenger car database), wheel lift, BDC laser, double dataset arms, Spindle-Lok, 3 centering pin kits, Hammerhead TDC laser. Mounting adaptors sold separately. |
$15,165.00
|
$15,165.00
|
|
row# |
FM02BLK |
ForceMatch HD Balancer-Includes SmartWeight, TPMS Specs (passenger car database), wheel lift, BDC laser, double dataset arms, Spindle-Lok, 3 centering pin kits, Hammerhead TDC laser. Mounting adaptors sold separately. Black. |
$15,165.00
|
$15,165.00
|
|
row# |
FM03 |
ForceMatch HD Balancer-Includes SmartWeight, TPMS Specs (passenger car database), wheel lift, BDC laser, double dataset arms, Spindle-Lok, 3 centering pin kits, ink-jet printer, side storage, Hammerhead TDC laser. Mounting adaptors sold separately. |
$16,125.00
|
$16,125.00
|
|
row# |
FM03BLK |
ForceMatch HD Balancer-Includes SmartWeight, TPMS Specs (passenger car database), wheel lift, BDC laser, double dataset arms, Spindle-Lok, 3 centering pin kits, ink-jet printer, side storage, Hammerhead TDC laser. Mounting adaptors sold separately. Black. |
$16,125.00
|
$16,125.00
|
|
row# |
FM01 |
ForceMatch HD Balancer-Includes SmartWeight, TPMS Specs (passenger car database), wheel lift, BDC laser, double dataset arms, Spindle-Lok, 3 centering pin kits, ink-jet printer, side storage. Mounting adaptors sold separately. |
$15,260.00
|
$15,260.00
|
|
row# |
FM01BLK |
ForceMatch HD Balancer-Includes SmartWeight, TPMS Specs (passenger car database), wheel lift, BDC laser, double dataset arms, Spindle-Lok, 3 centering pin kits, ink-jet printer, side storage. Mounting adaptors sold separately. Black. |
$15,260.00
|
$15,260.00
|
|
row# |
FM00 |
ForceMatch HD Balancer-Includes SmartWeight, TPMS Specs (passenger car database), wheel lift, BDC laser, double dataset arms, Spindle-Lok, 3 centering pin kits. Mounting adaptors sold separately. |
$14,300.00
|
$14,300.00
|
|
row# |
FM00BLK |
ForceMatch HD Balancer-Includes SmartWeight, TPMS Specs (passenger car database), wheel lift, BDC laser, double dataset arms, Spindle-Lok, 3 centering pin kits. Mounting adaptors sold separately. Black. |
$14,300.00
|
$14,300.00
|
Row# | Part# | Description | Manufacturer's List Price Dated | Contract Delivered Price Dated |
|---|---|---|---|---|
|
row# |
175-427-2 |
1 Adaptor-Centering bolt (Full set is 3 pieces). |
$82.00
|
$82.00
|
|
row# |
135-581-2 |
66mm pin, contained in Medium Duty Collet Kit (20-3116-1). Sold individually, order 5 for complete set. |
$39.00
|
$39.00
|
|
row# |
135-601-2 |
90mm pin, contained in Medium Duty Collet Kit (20-3116-1). Sold individually, order 5 for complete set. |
$39.00
|
$39.00
|
|
row# |
175-397-2 |
Adaptor-Flange Plate 7. See 5876-T. |
$455.00
|
$455.00
|
|
row# |
175-398-2 |
Adaptor-Flange plate adaptor 5×184, 15/4×165, 1/4×180. |
$435.00
|
$435.00
|
|
row# |
175-393-2 |
Adaptor-Heavy duty wheel support. |
$790.00
|
$790.00
|
|
row# |
175-401-2 |
Adaptor-Off road light truck pin (single pin). |
$50.00
|
$50.00
|
|
row# |
175-425-2 |
Adaptor-Sprinter Van centering bolt (Set of 3). |
$82.00
|
$82.00
|
|
row# |
175-400-2 |
Adaptor-Star pattern 4-arm medium duty clamp adaptor. |
$430.00
|
$430.00
|
|
row# |
175-396-2 |
Adaptor-Star pattern 5-arm clamp adaptor. |
$540.00
|
$540.00
|
|
row# |
175-420-2 |
Adaptor-Steel heavy duty pin short, individual part. (Full set is 5 pieces). |
$35.00
|
$35.00
|
|
row# |
20-2711-1 |
Balancer Centering Kit- Includes 6″ clamping cup, wingnut, spacer and 20-2683-1 collet kit. Combine with 20-2750-1 to create a Gen 3 BullsEye kit. |
$745.00
|
$745.00
|
|
row# |
20-2747-1 |
BullsEye collet and storage kit for LCD series and SmartWeight Pro balancers |
$895.00
|
$895.00
|
|
row# |
192-182-2 |
Cone-Heavy duty 219.9mm, Included in 20-3155-1 kit. |
$340.00
|
$340.00
|
|
row# |
192-181-2 |
Cone-Heavy duty 220.8mm, Included in 20-3155-1 kit. |
$340.00
|
$340.00
|
|
row# |
192-210-2 |
CONE-HUB DISC 4.88 inch / 124 mm, 6.06 inch / 154 mm |
$380.00
|
$380.00
|
|
row# |
192-227-2 |
Cone-Hub Disc Nissan NV. Solid Design centering disc #9. See 5876-T. |
$300.00
|
$300.00
|
|
row# |
192-183-2 |
Cone-Hub disk 4.55″. |
$265.00
|
$265.00
|
|
row# |
192-184-2 |
Cone-Hub disk 4.59″. |
$265.00
|
$265.00
|
|
row# |
192-185-2 |
Cone-Hub disk 4.77″. |
$215.00
|
$215.00
|
|
row# |
192-186-2 |
Cone-Hub disk 4.88″, 4.92″. |
$170.00
|
$170.00
|
|
row# |
192-188-2 |
Cone-Hub disk 5.25″, 5.46″. |
$265.00
|
$265.00
|
|
row# |
192-187-2 |
Cone-Hub disk 5.60″, 6.70″. |
$370.00
|
$370.00
|
|
row# |
192-242-2 |
Cone-Hub disk 8.66″, Included in 20-2761-2 and 20-2977-2 kits. |
$260.00
|
$260.00
|
|
row# |
192-211-2 |
Cone-Sprinter van cone 6.34″. |
$690.00
|
$690.00
|
|
row# |
20-3358-1 |
Economy MD collet kit provides broad coverage for most medium duty applications. Does not handle the large 8 lug/8.7″ bore found on some MD trucks. 20-2977-2 covers that application. Includes application chart for quick and easy adaptor look up. |
$1,080.00
|
$1,080.00
|
|
row# |
20-2288-1 |
HammerHead Top Dead Center Laser |
$865.00
|
$865.00
|
|
row# |
20-2274-2 |
Heavy Duty and Bus, 8-10 Lug |
$2,250.00
|
$2,250.00
|
|
row# |
20-2143-1 |
Inkjet Color Printer and Printer Shelf Kit- Works with generation III (LCD), generation IV (LCD TouchScreen – SWT and RFT) and generation V balancers. |
$864.00
|
$864.00
|
|
row# |
20-2761-2 |
KIT-ADAPTOR-TRUCK ECO |
$1,325.00
|
$1,325.00
|
|
row# |
20-3116-1 |
Medium duty collet kit provides broad coverage for most medium duty applications. Does not handle the large 8 lug/8.7″ bore found on some medium duty trucks. 20-3155-1 covers that application and includes 20-3116-1. Includes application chart. |
$1,890.00
|
$1,890.00
|
|
row# |
46-748-2 |
Medium duty collet spacer. Part of 20-3116-1. See 5876-T for applications. |
$310.00
|
$310.00
|
|
row# |
51-2912-2 |
Medium duty flange plate. Part of 20-3116-1. See 5876-T for applications. |
$805.00
|
$805.00
|
|
row# |
192-244-2 |
Medium duty universal collet #15. Part of 20-3116-1. See 5876-T for applications. |
$515.00
|
$515.00
|
|
row# |
192-245-2 |
Medium duty universal collet #16. Part of 20-3116-1. See 5876-T for applications. |
$515.00
|
$515.00
|
|
row# |
192-246-2 |
Medium duty universal collet #17. Part of 20-3116-1. See 5876-T for applications. |
$515.00
|
$515.00
|
|
row# |
76-463-2 |
Nut-M16 knurled nut, Included in 20-3155-1 kit. |
$9.00
|
$9.00
|
|
row# |
76-464-2 |
Nut-MD M10 knurled nut, Included in 20-3155-1 kit. |
$5.00
|
$5.00
|
|
row# |
175-399-2 |
One Adaptor-Pin light truck 66mm. (Full set is 5 pieces). |
$36.80
|
$36.80
|
|
row# |
175-402-2 |
One Adaptor-Steel pin. (Full set is 5 pieces). |
$35.00
|
$35.00
|
|
row# |
175-426-2 |
Pin used on certain Isuzu applications. Used with nut 76-486-2. |
$95.00
|
$95.00
|
|
row# |
135-582-2 |
Single pin in Medium Duty Collet Kit, 20-3116-1. Used on certain Isuzu, Mercedes and Freightliner applications. Sold individually. Order 5 for complete set. |
$51.00
|
$51.00
|
|
row# |
20-2286-2 |
Stand – HD adaptor tree. Standard with HD balancer. |
$215.00
|
$215.00
|
|
row# |
20-2610-2 |
Truck Kit- 3-arm adaptor for 6 lug Sprinter/Isuzu truck. Includes 192-211-2 cone, 175-424-2 adaptor, 175-425-2 sprinter pins (set of 3), 76-486-2 knurled nut (set of 3), 175-426-2 Isuzu pins (set of 3), 175-427-2 sprinter pins(old) (set of 3). |
$825.00
|
$825.00
|
|
row# |
20-3155-1 |
Truck/Car Super set: contains 20-2274-2 HD truck kit, 20-3116-1 MD Centering Kit, BullsEye collets with storage and 4.5″, 6″ and 9″ mounting cups. Provides complete coverage from Kia to Kenworth. Replaces 20-2762-2. |
$4,740.00
|
$4,740.00
|
|
row# |
20-1602-1 |
TruckChuck Wheel & Drum Balancing Kit, Includes Chuck 175-286-2, Clamp Cup 175-296-2, Protector Sleeve 106-127-2, and 20-1854-2 Extended Jaws Kit |
$1,030.50
|
$1,030.50
|
Row# | Part# | Description | Manufacturer's List Price Dated | Contract Delivered Price Dated |
|---|---|---|---|---|
|
row# |
PE |
Heavy Truck and Bus Pit Rack, 10,000 lb. axle capacity, Includes pedestals, (2) front stairs, and 50 ton work beam. For 36″ deep pit. |
$16,200.00
|
$16,200.00
|
|
row# |
PF |
Heavy Truck and Bus Pit Rack, 18,000 lb. Axle Capacity. Includes pedestals, (2) front stairs, and 100 ton work beam. For 58″ deep pit. |
$28,000.00
|
$28,000.00
|
|
row# |
PT |
PT Pit Group 18,000 lb. axle capacity. Includes pedestals and (2) front stairs. For 58″ deep pit. Must add 20-3108-1, Contractor pre-kit. |
$35,000.00
|
$35,000.00
|
Row# | Part# | Description | Manufacturer's List Price Dated | Contract Delivered Price Dated |
|---|---|---|---|---|
|
row# |
123-15-1-001 |
36″ Steel Steps for Pit racks. |
$336.00
|
$336.00
|
|
row# |
118-668-2 |
Cross Beam Adaptor, Used to spread adaptor lift points. Typically needed when lifting from springs in caster adjustment of large trucks for 133-77-2 jack only. |
$1,035.00
|
$1,035.00
|
|
row# |
11-637-1 |
Jack Tray for T-Pit rail kit only. Jack not included. Accomodates many styles of jacks, including bottle jacks. |
$4,020.00
|
$4,020.00
|
|
row# |
20-1513-1 |
New Style Wheel Stop (Kit includes two) |
$1,200.00
|
$1,200.00
|
|
row# |
20-3107-1 |
Pre-Contractor / Pre-installation kit for optional 10-Ft Jack Rail (20-1517-1). Order (1) 20-3107-1 for each 20-1517-1. Required prior to pouring pit. Includes 2 angle rollers and 2 stop rollers. |
$525.00
|
$525.00
|
|
row# |
20-3108-1 |
PT Pit Pre-Contractor / Pre-installation kit. Required prior to pouring pit. Order (1) 20-3108-1 for each PT group. Includes 2 angle rollers, 1 left hand angle roller assembly, and 1 right hand angle roller assembly. |
$1,325.00
|
$1,325.00
|
|
row# |
20-1517-1 |
T-Pit Rail 10′ Extension Kit for PF pit. Also requires (1) 20-3107-1 pre-install kit per (1) 20-1517-1 ordered. |
$4,400.00
|
$4,400.00
|
|
row# |
20-869-1 |
T-Pit Rail Kit for PF pit. (20′ length). Also require (2) 20-3107-1 pre-install kit per (1) 20-869-1 ordered. |
$8,600.00
|
$8,600.00
|
|
row# |
118-667-2 |
Twin Lift Adaptor, Used when more than 17,600 lbs of load need lifted at a single point for 133-77-2 jack only. |
$495.00
|
$495.00
|
|
row# |
51-555 |
Wear Plate for Work Beam |
$75.80
|
$75.80
|
Row# | Part# | Description | Manufacturer's List Price Dated | Contract Delivered Price Dated |
|---|---|---|---|---|
|
row# |
TCX625PHD |
Compact Heavy Duty Truck Tire Changer “Plus” ~ Suited for over-the-road truck tires. Includes standard accessories plus mounting lever, 2 ramps, ALU jaw covers, v-cover. 208-230V, 60Hz, 1-ph, (L6-20P Plug Provided). |
$19,350.00
|
$19,350.00
|
|
row# |
TCX625HD |
Compact Heavy Duty Truck Tire Changer ~ Suited for over-the-road truck tires from 14.5″ to 24.5″ Tulip clamping. Includes Alu and steel wheel bead clamps, two bead loosening rollers, and demount hook. 208-230V, 60Hz, 1-ph, (L6-20P Plug Provided). |
$18,125.00
|
$18,125.00
|
|
row# |
TCX645HD |
TCX645HD heavy duty tire changer, standard accessories. 208/230V, 60 Hz, 3 phase. Red only. |
$24,500.00
|
$24,500.00
|
Row# | Part# | Description | Manufacturer's List Price Dated | Contract Delivered Price Dated |
|---|---|---|---|---|
|
row# |
RP11-801254494 |
Aluminum jaw protectors for TCX625HD. Prevents possible damage to center bore of the wheel when clamping. |
$367.00
|
$367.00
|
|
row# |
RP11-2016908 |
Disk style roller for the TCX625HD. Especially helpful when removing the locking ring on multi-piece wheels. May also be used for outer bead loosening. NOTE: not possible to fit Disk Roller into the inner roller position for back bead loosening. |
$1,402.00
|
$1,402.00
|
|
row# |
RP11-8-12100155 |
Jaw Extensions V2 – TCX640HD 5″ Clamping Extensions for a total clamping range of 56″. |
$1,147.00
|
$1,147.00
|
|
row# |
RP11-8-12100181 |
New mounting bar. Includes two heads – one optimized for steel wheels and one optimized for wheel protection on aluminum wheels. The aluminum wheel head uses solid polymer blocks instead of inserts for long life. |
$553.00
|
$553.00
|
|
row# |
RP11-8-12100182 |
New plastic head upgrade. Fits on any mounting bar previously shipped. |
$140.00
|
$140.00
|
|
row# |
RP11-8-12100039 |
Pocket V Cover – filler plate for the area between rollers. |
$185.00
|
$185.00
|
|
row# |
RP11-2306040 |
RT Truck Roller for TCX640HD, Mounting/demounting roller for typical truck tires. |
$515.84
|
$515.84
|
|
row# |
RP11-8-12100178 |
Set of 5 replacement inserts for mounting lever RP11-8-12100177. |
$52.00
|
$52.00
|
|
row# |
RP11-801251904 |
Skidder clamp for TCX640HD tire changer. Assists user in servicing “Skidder” style tires. |
$586.00
|
$586.00
|
|
row# |
RP11-8-12100040 |
TCX625 Ramp- One ramp to ease rolling tire onto changer. |
$185.00
|
$185.00
|
|
row# |
RP11-8-12100041 |
TCX625 tulip clamp jaw inserts. 8 pieces. For “drop roller” versions of the TCX625 only. |
$79.40
|
$79.40
|
|
row# |
RP11-8-12100172 |
TCX640 Alloy Jaw Insert V2 – For TCX640HD with serial number IIC735988 or greater. |
$114.00
|
$114.00
|
|
row# |
20-3453-1 |
TCX645HD Wireless Controller Kit. |
$2,350.00
|
$2,350.00
|
